VAN GÓC MỞ RỘNG AV210E C/N 042N4459

Gross weight

6.44 kg

Net weight

5.44 kg

EAN

5702423194575

Ambient temperature range [°C] [Max]

60 °C

Ambient temperature range [°C] [Min]

-30 °C

Ambient temperature range [°F] [Max]

140 °F

Ambient temperature range [°F] [Min]

-22 °F

Body material

Stainless steel

Closing

Against flow

Connection Internal/External

Internal

Connection size [in]

2

Connection type

G

Control head diameter [mm]

110 mm

Control pressure range [bar] [Max]

8 bar

Control pressure range [bar] [Min]

4 bar

Control pressure range [psig] [Max]

116 psig

Control pressure range [psig] [Min]

58 psig

Cv value [gal/min]

77.4 gal/min

Differential pressure [bar] [Max]

10 bar

Differential pressure [bar] [Min]

0 bar

Function

NC

Kv value [m³/h]

67 m3/h

Max. test pressure [bar]

37.5 bar

Max. test pressure [psig]

544 psig

Max. Working Pressure [bar]

25 bar

Max. Working Pressure [psig]

363 psig

Medium temperature range [°C] [Max]

180 °C

Medium temperature range [°C] [Min]

-30 °C

Medium temperature range [°F] [Max]

356 °F

Medium temperature range [°F] [Min]

-22 °F

Operation

Piston (angle)

Orifice size [mm]

50 mm

Packing format

Single pack

Product group

Externally operated valves

Product name

Angle-seat ext operated valve

Quantity per packing format

1 pc

Seal Material

PTFE

Type

AV210E
